ABB TPS48 Series - Disassembly and Assembly

Operation Manual / TPS48-D/E.. - TPS61-D/E..
Removal and installation
7
Installing the turbocharger
7.4
Page 91
© Copyright 2016 ABB. All rights reserved.
September 2016 HZTL2410_EN Revision E
If present:
 Fit speed sensor and plug in cable connector.
 Adapt and fit bearing casing insulation (A).
 Adapt and fit sheet metal (B) of bearing casing insulation.
Version with water-cooled bearing casing:
 Remove the screw plugs on the water connections and fit the water
pipes according to the enginebuilder's specifications.
