TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION
1
LCD
Parameters *Default
System parameters
Start Automatic Configuration
Power distribution systems (see Fig. 2.2)
Source 1 1 Phase, 2 Wire
2 Phases, 3 Wire (Split Neutral)
3 Phases, no Neutral (3ph3w)
3 Phase with Neutral (3ph4w)*
3 Phase, High-Leg Delta
Source 2 1 Phase, 2 Wire
2 Phases, 3 Wire (Split Neutral)
3 Phases, no Neutral (3ph3w)
3 Phase with Neutral (3ph4w)*
3 Phase, High-Leg Delta
Rated Voltage
200 V (3ph), 208 V (3ph), 220 V (3ph), 230 V (3ph), 240 V (3ph), 277 V (3ph), 347 V
(3ph), 380 V (3ph), 400 V (3ph)*, 415 V (3ph), 440 V (3ph), 460 V (3ph), 480 V (3ph),
200 V (1ph), 220 V (1ph), 230 V (1ph), 240 V (1ph), 254 V (1ph), 265 V (1ph), 277 V
(1ph), 318 V (1ph), 333 V (1ph), 347 V (1ph), 380 V (1ph), 400 V (1ph), 415 V (1ph),
440 V (1ph), 460 V (1ph), 480 V (1ph)
Rated Frequency
50 Hz*
60 Hz
Neutral Position
Pole 4*
Pole 1
Phase Sequence
ABC*
ACB
Not Enabled
Continued on the next page
