TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION
1
LCD, TOUCH
5.6.1.3 Access from the display /
Ekip Com Modbus RTU –module
With modules energized the presence of
the modules on the module slot activates
additional menus on the display.
The following table illustrates the path for
accessing the configuration parameters
of the modules from the display:
Settings (*Default value) Description
:
Modules (Optional modules)
Ekip Com Modbus RTU
Serial address Address to be assigned to the modules.
NOTE: devices connected to the same network
must have different addresses
Baudrate
Data transmission speed
Physical protocol
:
—
Table 5.7 The path for accessing the configuration parameters of the Ekip Com Modbus RTU -module from the display
About Description
:
Modules (Optional modules)
Ekip Com Modbus RTU
SN Serial number
Software version
:
—
Table 5.8 Information of Ekip Com Modbus RTU -module in HMI
The following table illustrates the path
from the display for accessing informa-
tion on the module:
