TruONE® ATS, INSTALLATION AND OPERATING INSTRUCTION
1
LCD, TOUCH
5.6.3.3 Access from the display /
Ekip Com DeviceNet –module
With modules energized the presence of
the modules on the module slot activates
additional menus on the display.
The following table illustrates the path for
accessing the configuration parameters
of the modules from the display:
Settings (*Default value) Description
:
Modules (Optional modules)
Ekip Com DeviceNet
MAC address  Address to be assigned to the
modules. IMPORTANT: devices
connected to the same network
must have different addresses
Baudrate  Data transmission speed
:
—
Table 5.13 The path for accessing the configuration parameters of the Ekip Com DeviceNet -module from the display
The following table illustrates the path
from the display for accessing informa-
tion on the module:
About Description
:
Modules (Optional modules)
Ekip Com DeviceNet
SN Serial number
 Software version
:
—
Table 5.14 Information of Ekip Com
DeviceNet -module in HMI
