5.6.4.2 Access from the display
/ Ekip Com Modbus TCP –module
With modules energized the presence of
the modules on the module slot activates
additional menus on the display:
• For setting the function and addressing
of the modules.
• In order to display information on the
modules.
The following table illustrates the path
from the display, for setting the function
and addressing of the modules:
Settings (* Default value) Description
:
Modules (Optional modules)
Ekip Com Modbus TCP
Function HTTP Server HTTP Server operating mode.
TCPModbus* Communication module operating mode.
Force Static IP address Off* Dynamic IP address.
On Static IP address.
Static IP Address Displayed with static IP Address enabled, it
must be selected in order to insert the IP
Address of the modules.
Static Network Mask Displayed with static IP Address enabled, it
must be selected in order to insert the subnet
mask of the modules.
Static Gateway addr Displayed with static IP Address enabled, it
must be selected in the presence of multiple
subnets, in order to insert the IP Address of
the node to which the modules are connected.
:
—
Table 5.17 The path for setting the function and addressing of the
modules of the Ekip Com Modbus TCP -module from the display
