TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I 57
Menu: Device Info
Menu / parameter
Description
… /Device Info
Device Type
Displays device type.
Serial Number
Displays device serial number.
Software Version
Displays device software version.
Hardware Version
Displays device hardware version.
HART Tag
Displays the HART Tag.
HART Descriptor
Displays the HART Descriptor.
Operation Time
Displays the operation hours of the device.
Menu: Display
Menu / parameter
Description
… /Display
Display Value
Selects the process value shown in Bargraph view of process display
•
Process Variable: Calculated process variable (PV)
•
Sensor 1: Measured value from Sensor 1
•
Sensor 2: Measured value from Sensor 2
•
Electr. Meas. S1: Measured value from Sensor 1 (in Ω or mV)
•
Electr. Meas. S2: Measured value from Sensor 2 (in Ω or mV)
•
Temp. Electronics: Temperature of the transmitter
•
Output Current: Output current of 4 to 20 mA signal
• Output %: Output value as % of measuring range
Bargraph
Selects whether or not a
Bargraph is shown
Bargraph View
•
Output Current: Output current of the 4 to 20 mA signal
• Output %: Output value as % of measuring range
Language
Selects the menu language
•
German
•
English
Contrast
Sets the display contrast
Value range:0 to 100%
