ABB TTF300 - HART Device Setup Parameters (SW-Rev. 03.00) - Input;PV Unit

TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I 67
Menu / parameter
Description
… / Device Setup / Input Sensor 1
… / Device Setup / Input Sensor 2
Sensor Type
Selects sensor type:
Table of all sensor types: see “
… / Easy Setup / Sensortype S1 ”
R
-Connection
Sensor connection type relevant for all Pt, Ni, Cu resistance thermometers
•
two-wire: Sensor connection type in two-wire technology
•
three-wire: Sensor connection type in three-wire technology
• four-wire: Sensor connection type in four-wire technology
2
-wire Resistance
Sensor line resistance relevant for all Pt, Ni, Cu resistance thermometers with a two
-wire circuit
Value range:0
to 100 Ω
Thermocouple CJC
Cold junction compensation for thermocouples:
•
Internal:Use of internal reference junction temperature of the transmitter when using thermal compensating cable.
•
External - fixed:Use of external fixed reference junction temperature of the transmitter when constant thermostat
temperature is used (can be set with external reference junction temperature 2).
•
None: no thermocouple cold junction compensation (CJC)
• Temperature sensor 1: Use of Sensor 1 as reference junction temperature for Sensor 2
Ext. CJC Temperature
Relevant for external cold junction
compensation , specification of constant external cold junction temperature
Value range:
-50 to 100 °C
… / Device Setup / PV Measured range
PV Unit
Selects the physical unit for the sensor measuring signal
Units: °C, °F, °R, K, mV, Ω, V, kΩ
PV Lower Range Value
Defines the value for 4 mA (adjustable)
PV Upper Range Value
Defines the value for 20 mA (can be configured)
