ABB XAC19590 - Table 44: Overview of Tightening Torques; Table 45: Tightening Torque, Insulation

Operation Manual / 4 Product description / A200-L
8 Disassembly and assembly / 8.14 Table of tightening torques
© Copyright 2018 ABB. All rights reserved. HZTL4036_EN Revision M August 2018
Position Part number A265-L A270-L A275-L A280-L
22 57005 M12
50
M12
50
M16
80
M20
160
61
1)
61009
51087
M16
30
2)
140
M18
40
2)
200
M22
50
2)
380
M24
80
2)
480
62
1)
72011 M18
370
M20
500
M24
900
M27
1300
63
1)
72004 M14
130
M16
200
M18
300
M20
420
63a 72002 M14
40
M16
60
M18
80
M20
100
64 77015 M5
6
M6
10
M8
25
M8
25
65 56014 M10
35
M10
35
M10
35
M12
65
66 81125 G1/2"
45
G1/2"
45
G1/2"
45
G1/2"
45
67 86505 M18x1.5
150
M18x1.5
150
M18x1.5
150
M27x2
320
Table44: Overview of tightening torques
1) Tighten crosswise
2) Pre-tightening torque of the screws
u Use hydraulic tool for tightening torques exceeding 500 Nm.
Thread size Tightening torque [Nm]
M8 28
M10 45
M12 (compressor casing insulation) 50
Table45: Tightening torque, insulation
Page 89 / 108
