2 Removal and installation
2.1 Turbocharger weight
Lifting gear with a sufficient load limit must be used for removing and installing the tur-
bocharger. The following weight specification applies to the heaviest variant possible. De-
pending on the specification, the weight specified on the rating plate may be lower than the
standard value specified here.
Weights of the complete turbocharger
Product Weight [kg]
A265-L 2600
A270-L 3800
A275-L 6300
A280-L 8700
Table2: Weights A200-L with filter silencer
2.2 Removing the turbocharger
WARNING
Risk of tipping
If the turbocharger is not sufficiently supported or not supported at all dur-
ing removal and installation, it may tip over and cause severe injury to per-
sonnel or accidents resulting in fatalities.
u Support the turbocharger at a suitable location.
u Secure with lifting gear wherever possible.
Wear safety helmet.
u Loosen cable to speed sensor.
u Disconnect all pipes according to the instructions of the enginebuilder.
u Check lifting gear.
u Fasten lifting gear on suspension eyes of the bearing casing and tauten.
