Operation Manual / A100-L
9 Disassembly and assembly / 9.15 Fitting the gas inlet casing (
≤
A175-
L)
© Copyright 2021 ABB. All rights reserved.
HZTL4034_EN
Rev.T
December 2021
9.15
Fitting the gas inlet casing (
≤
A175-L)
Fig.50: Fitting the gas outlet casing (A175-L and smaller)
Product
Size
Tightening torque [Nm]
A165-L
M16
30
1)
/ 140
A170-L
M18
40
1)
/ 200
A175-L
M22
50
1)
/ 380
Table35: Tightening torque (51087)
1) Pre-tightening torque of the nuts
Page 91 / 141
