Operation Manual / A100-L
9 Disassembly and assembly / 9.24 Table of tightening torques
© Copyright 2021 ABB. All rights reserved. HZTL4034_EN Rev.T December 2021
Position Part
number
A165-L A170-L A175-L A180-L A185-L A190-L
22 57005 M12
50
M12
50
M16
80
M20
160
M20
160
M24
280
61
1)
51087 M16
30
2)
140
M18
40
2)
200
M22
50
2)
380
M24
80
2)
480
M27
100
2)
700
M30
100
2)
920
62
1)
72011 M18
370
M20
500
M24
900
M27
1300
M30
1700
M33
2300
63
1)
72004 M14
130
M16
200
M18
300
M20
420
M22
570
M24
710
63a 72002 M14
40
M16
60
M18
80
M20
100
M22
120
M24
140
64 77015 M5
6
M6
10
M8
25
M8
25
M10
45
M10
45
65 56014 M10
35
M10
35
M10
35
M12
65
M12
65
M16
170
66 81125 G1/2"
45
G1/2"
45
G1/2"
45
G1/2"
45
G1/2"
45
G1/2"
45
67 86505 M18x1.5
150
M18x1.5
150
M18x1.5
150
M27x2
320
M27x2
320
M27x2
320
Table44: Overview of tightening torques
1) Tighten crosswise
2) Pre-tightening torque of the screws
u Use hydraulic tool for tightening torques exceeding 500 Nm.
Tightening torque, insulation
Thread size Tightening torque [Nm]
M8 28
M10 45
M12 (compressor casing insulation) 50
Table45: Tightening torque, insulation
