System Overview
OPTIS™ Integrated Next Operation and Maintenance Manual – 600173796 Rev. A 23
Drive Motor and Optical Controller (DOC)
The DOC provides bed-side control of the most important OCT imaging functions.
Refer to the installed software User Manual for Dragonfly™ Imaging Catheter
connection details.
Figure 5. Drive Motor and Optical Controller (DOC)
3
4
5
6
2
1
7
1. Stop button
2. Enable button
3. (button not used)
4. Lock indicator
light
5. Catheter
connection port
6. Catheter
connector hub
7. Unload button
