Introduction Of BH6 Features 1-1
Chapter 1 Introduction Of BH6 Features
The motherboard is designed for a new generation CPUs. It supports the Intel SLOT1
structure (Pentium

II/III and Celeron
™
processors), up to 768MB of memory, super I/O,
and Green PC functions. The motherboard provides high performance for server
systems and meets the requirements for desktop system for multimedia in the future.
(1) Specifications
1. CPU
! CPU SOFT MENU
™
II eliminates the need for jumpers or DIP switches
needed to set CPU parameters
! Employs switching type regulators to stabilize CPU operation
! Supports 66 and 100MHz MHz CPU external clock speeds
! Supports Intel
®
Pentium
®
III 450 ~ 500MHz processor cartridge (Based on
100MHz)
! Supports Intel
®
Pentium
®
II 350 ~ 450MHz processor cartridge (Based on
100MHz) and Pentium
®
II 233 ~ 333MHz processor cartridge (Based on
66MHz)
! Supports Intel
®
Celeron
™
266MHz~466MHz processor (Based on 66MHz)
2. Chipset
! Intel
®
440BX chipset (82443BX and 82371EB)
! Supports Ultra DMA/33 IDE protocol
! Supports Advanced Configuration and Power Management Interface(ACPI)
! Accelerated Graphics Port connector supports AGP 1x and 2x mode (Sideband)
3.3V device
3. Cache Memory
! Level 1 and Level 2 cache built into Intel
®
Pentium
®
II/III processor cartridge
! Level 1 cache (without L2 cache) built into Intel
®
Celeron
™
processor
"
4. Memory (DRAM)
! Three 168-pin DIMM sockets support SDRAM modules
! Supports up to 768MB
#
! ECC support
5. System BIOS
! AWARD BIOS
! Supports Plug-and-Play (PnP)
! Supports Advanced Configuration Power Interface (ACPI)
! Supports Desktop Management Interface (DMI)
! Year 2000 compliant
