3-34 Chapter 3
#
##
# Onboard IR Function:
Three options are available:
" IrDA (HPSIR) mode.
" ASK IR (Amplitude Shift Keyed IR) mode.
" Disabled.
#
##
# RxD , TxD Active:
Set IR transmission/reception polarity as High or Low.
#
##
# IR Transmission Delay:
Set IR transmission delays 4 character-time(40 bit-time) when SIR is
changed from RX mode to TX mode.
Onboard Parallel Port:
Sets the I/O address and IRQ of the onboard parallel port. Four options are
available: Disable, 3BCh/IRQ7, 278h/IRQ5 and 378h/IRQ7. Default is
378h/IRQ7.
#
##
# Parallel Port Mode:
Can be set as ECP, EPP, ECP+EPP, or Normal (SPP) mode. Default is
Normal (SPP) mode.
#
##
# ECP Mode Use DMA:
When the mode selected for the onboard parallel port is ECP, the DMA
channel selected can be Channel 1 or Channel 3.
#
##
# EPP Mode Select:
When the mode selected for the onboard parallel port is EPP, two EPP
version options are available: EPP1.7 and EPP1.9.
