Quick Installation
A-5
Pin number Name of the signal or signification
1 Ground
2 +12V
3 Sense signal
Some jumpers are reserved for future functions or are not to be adjusted in
normal operation. Adjust them according to the following recommendations.
CCMOS
Always put jumper on pin 1 and pin 2, this is default setting.
Parameters and CPU settings after you have followed the steps described above
and completed the installation, when you power the computer on, you will see
the following message displayed
PRESS DEL TO ENTER SETUP
Press immediately Del key to enter BIOS Setup. Select Load Setup Defaults,
than enter CPU Soft Menu to set CPU parameters.
Adjusting other jumpers
BIOS Setup
