PREPARATIONS, INSTALLATION AND TAKING INTO OPERATION
6
Preparations, installation and taking into
operation
Introducing the product
The ABL Wallbox model variants are entirely manufactured in Germany and at all times
comply with the regulations and norms for the charging of electric vehicles applicable
throughout Europe according to IEC 61851-1, Mode 3 – please also refer to the section
on”Guidelines & Norms” on page 18.
We place the highest value on user safety in all our products. Your wallbox therefore
offers integrated DC fault current detection, guaranteeing the faultless operation of
the internal RCCB in case of DC fault currents generated by the vehicle.
The wallbox is especially easy to operate during everyday use: LED lights on the wall-
box housing cover allow you to check the current operating status at any time. Should
a malfunction occur, you can identify the cause by its specific LED error code without
having to open the housing. After being taken into operation by a specialist contractor,
the ABL Wallbox is ready for charging at any time, while each charging process must
be separately authorized via the integrated RFID module (model variants 3W14A2 and
3W22A2 only).
Unpacking and components included
The ABL Wallbox package includes a range of accessory components needed for in-
stallation and proper operation. Therefore, please check immediately after unpacking
(together with the customer, if required) whether the following components are in-
cluded:
COMPONENT QUANTITY DESCRIPTION
Wallbox 1
Wallbox, consisting of plastic housing with lockable
cover and separate mounting plate.
Quick start guide 1
Quick start guide including safety notices in printed
form
Installation kit 1
Set of fixings for wall mounting, consisting of 2 x 4
screws as well as matching wall plugs, triangular key,
strain relief including screws (2 pcs), sealing grom-
mets for openings at the back of the housing (3 pcs)
Should one or more components be missing after unpacking, please contact your local
ABL distributor immediately.
