PREPARATIONS, INSTALLATION AND TAKING INTO OPERATION
7
PLEASE NOTE!
The carton in which the ABL Wallbox is delivered offers optimal protec-
tion against external influences during transport and storage. If possible,
keep this carton and use it to pack the ABL Wallbox, should you need to
send it to the manufacturer or otherwise transport it because of a mal-
function or similar.
Identifying your model variant
The ABL Wallbox is available in a range of model variants that are mechanically and
electrically tailored to different application profiles. When you open the housing cover
for installation, you will find behind it on the lower part of the electronic components
cover a product information label, which will carry the ABL model number. For identi-
fication, the model code (3WXXXX) as well as the power supply ratings (voltage, fre-
quency, current) indicated below it are especially relevant.
Using the ABL model number, please always
ensure before installation that your wallbox
model variant is the one whose installation
is described in this document.
You can find a list of the wallbox model variants described in this manual in the table
below.
MODEL GRID CONNECTION MODEL VARIANT
3W14A1
230 V
50 Hz 32 A
Three-wire system with three outer conductors and
no neutral conductor; two integrated charging sock-
ets according to IEC 62196-2 Type 2 for the sepa-
rately available Mode 3 charging cable;
internal Type
A RCCB; internal DC fault current detection
; max.
charging output up to 2x 7.2 kW
3W14A2
230 V
50 Hz 32 A
Three-wire system with three outer conductors
and no neutral conductor; two integrated charging
sockets according to IEC 62196-2 Type 2 for the
separately available Mode 3 charging cable; access
control via RFID;
internal Type A RCCB; internal DC
fault current detection
; max. charging output up to
2x 7.2 kW
3W14A100001
2016-08-17
3W14A1
~230V 50Hz 32A
IP44
IEC 61851-1
IEC 61439-7 ACSEV
MADE IN GERMANY
ABL SURSUM Bayrische Elektrozubehör GmbH & Co. KG
3W14A100001
