ABL eMH3 Installation Manual

APPENDIX
16
Appendix
Technical specifications
MODEL VARIANT 3W14A1 3W14A2 3W22A2
Compliance IEC 61851-1 / 61439-7
Grid connection for supply cable sizes of max. 4 x 16 mm²
for supply cable sizes
of
max. 5 x 16 mm²
Rated voltage 230 V 230 / 400 V
Rated current 15 A, 1-phase 30 A, 3-phase
Rated frequency 50 Hz
Max. output 2 x 7.2 kW 2 x 11 kW
Charging outlet
2 x lockable Type 2 charging sockets
Circuit protection devices
Type A 30 mA RCCB and DC-RCM electronic
DC fault current detector, IΔN d. c. > 6 mA
Control /
Customization
Internal RS485 and USB interfaces
(no user access)
Access control - RFID
Operating temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Overvoltage category III
Degree of pollution 3
Degree of protection
(housing)
IP44
Impact strength IK08
Dimensions incl.
mounting plate
492 x 400 x 194 mm
(H x W x D)
Dimensions
w/o mounting plate
492 x 400 x 162 mm
(H x W x D)
Mounting plate dimen-
sions
477.9 x 376.4 x 32 mm
(H x W x D)
Maximum elevation ≤ 2,000 m AMSL (above mean sea level)
Weight per unit incl.
mounting plate
ca. 5.7 kg
Weight per unit
w/o mounting plate
ca. 4.7 kg

ABL eMH3 Specifications

General

Category	Battery Charger
Connector Type	Type 2
Number of Charging Points	1
Protection Rating	IP54
Charging Current	32 A
Input Voltage	400 V AC
Protection Class	I
Output Voltage	400 V AC
Output Current	32 A
Operating Temperature	-25°C to +50°C
Cooling Method	Natural Convection
Model	eMH3
Protection Features	Overcurrent protection, overvoltage protection, short circuit protection
Charging Power	up to 22 kW
