ABL eMH3 Installation Manual

APPENDIX
19
Guideline Description
2012/19/EU WEEE Guideline
2014/35/EU Low voltage directive
ElektroG Electrical and Electronic Device Statute
Device safety standards
Standard Description
IEC 61851-1 Ed 2.0:2010 Conductive charging systems for electric vehicles –
Part 1: General requirements
IEC/TS 61439-7:2014 Part 7: Switching device combinations for specific
applications such as marinas, campgrounds, market
squares, charging stations for electric vehicles
DIN EN 61851-1: 2012-01 Conductive charging systems for electric vehicles –
Part 1: General requirements
E DIN EN 61851-22:2011-04 Conductive charging systems for electric vehicles –
Part 22: AC charging station for electric vehicles
HD 60364-7-722:2012 Low voltage installations – Part 7-722: Power supply
for electric vehicles
For Germany only
Standard Description
DIN VDE 0100-722:2012-10
Installation of low voltage equipment – requirements
for operation in special sites, premises and installa-
tions – power supply for electric vehicles
Classes of protection & Degrees of protection
Class of protection /
Degree of protection
Description
The device complies with IEC protection class 1.
IP 44
Degree of protection of the device (protection against dust
in harmful quantities and protection from splashing water)

ABL eMH3 Specifications

General

Category	Battery Charger
Connector Type	Type 2
Number of Charging Points	1
Protection Rating	IP54
Charging Current	32 A
Input Voltage	400 V AC
Protection Class	I
Output Voltage	400 V AC
Output Current	32 A
Operating Temperature	-25°C to +50°C
Cooling Method	Natural Convection
Model	eMH3
Protection Features	Overcurrent protection, overvoltage protection, short circuit protection
Charging Power	up to 22 kW
