9. Technical data
Model number HDCC72510
Image sensor 1/3 inch progressive scan CMOS
Camera type Vario dome
Resolution 1080p25, 1080p30
Pixels (effective) 1920 (H) x 1080 (V)
Lens 2.8–12 mm, varifocal lens (manual)
Focus Manual, with focus peak value display
Horizontal angle of view 32°–92°
Day/night switching Electromechanical IR cut filter
Minimum illumination (colour) 0.1 Lux
Minimum illumination (IR) 0.001 Lux (image integration on)
Minimum illumination (IR) 0 Lux
Noise reduction 2D DNR/3D DNR
Electronic shutter control 1/25 s to 1/50,000 s
Camera control On-screen display (OSD)
Backlight compensation DWDR, BCL, HSBLC
Privacy masking Eight freely configurable areas
Digital zoom Yes
Video system HD-TVI
IR LEDs 24
IR range 20 m
Smart IR Yes
Connections
Video signal (HD-TVI, BNC), video signal (FBAS, BNC), power
supply (DC), 2-pin (for WDR on/off)
Power supply 12 V DC ± 10%, 24 V AC ± 10%
Power consumption Max. 450 mA (max. 5 W)
Operating temperature -20°C–+60°C
Humidity Max. 90%
Dimensions (H x)
125 x 143 mm
Weight 950 g
The IR range is strongly dependent on the environmental conditions. If the area in the
camera's field of view reflects poorly or if there are no objects within the max. illumination
range, the brightness of the video image at night may be too low. This will result in poor
usability of the video image.
In addition, when installing the camera it must be ensured that no objects are located in
close proximity to the camera's field of view (e.g. roof gutter or wall). These objects can
reflect back the IR light, resulting in circular fading on the video image in the opposite
direction to the object.
