3. Assembly / Installation
ATTENTION!
The camera must be disconnected from the mains voltage during installation.
3.1. Installing the Camera Without a Wall Mount
You have the option of placing the camera on a flat surface, such as a shelf or cupboard. There should
be no large objects between the camera and the base station as these may affect the transmission
between the devices.
Attention!
Place the camera on the edge of the shelf, otherwise the white light LED may cause cross
fading in the camera image.
Please note that no objects are placed directly in front of the camera lens to avoid
crossfades.
The camera should not be placed on a glass shelf as reflections may occur.
installation site
The camera is suitable for both outdoor and indoor use.
Do not place the camera near heaters, stoves, other heat sources or in direct sunlight.
Operate the device only in locations with temperatures within the permissible ambient
temperature range of -20°~50°C.
3.2. Installing the Camera with Wall Bracket
Pre-drill the holes using the drilling template. Unscrew the cover of
the wall bracket and mount the floor plate to the wall / ceiling using
the supplied mounting material.
Insert the ball joint and screw on the cover, do not tighten it to align
the camera.
