Abus PPIC90000 Instruction Manual

14
English
3.5. Installing the Camera and Base Station
The camera with protection class IP65 is suitable for outdoor use. The base station is intended for
indoor installation only. The base station supports up to two battery cams. The pairing process of the
base station into the app is described under 4. App2Cam Plus: First Access. For external access to
the camera, you need a 2.4 GHz router with Internet access.
reference
Place the base station so that it is not covered by objects.
Ensure optimum ventilation of the base station.
Routers with 5 GHz frequency are not supported. For dual frequency routers it is
recommended to separate the two frequencies by name.

Abus PPIC90000 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Form factor	-
Mounting type	Wall
Product color	Black, White
Housing material	Plastic
International Protection (IP) code	IP65
Camera pan control	No
Minimum illumination	1 lx
Field of view (FOV) angle	115 °
Number of sensors	1
Fixed focal length	2.9 mm
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Number of users	3 user(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Power source type	Battery, DC
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	51 mm
Width	103 mm
Height	54 mm
