Abus PPIC90000 Instruction Manual

38
English
Environment mode
Here you have the possibility to
select the mains frequency for your
camera.
The following options are available:
Indoor (50Hz), Indoor (60Hz) and
Outdoor.
Standard value Germany: 50 Hz
PIR Sensitivity
Here you can set the sensitivity of the
PIR sensor.
With a high sensitivity setting, the
camera triggers at low heat
movement. This can lead to false
alarms.
Heat sources such as heaters or fan
heaters can cause false alarms, so
do not point the camera at them.
Delete device
You can delete a camera from the
base station. Confirm the deleting
process by clicking OK.
To pair a camera in a base station,
press the pairing button on the base
station and wait for the voice
command "Ready for camera
connection". Now press the power
button on the camera three times. As
soon as the camera connection has
been established, the voice
command "Camera connection
successfully completed" is issued.

Abus PPIC90000 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Form factor	-
Mounting type	Wall
Product color	Black, White
Housing material	Plastic
International Protection (IP) code	IP65
Camera pan control	No
Minimum illumination	1 lx
Field of view (FOV) angle	115 °
Number of sensors	1
Fixed focal length	2.9 mm
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Number of users	3 user(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Power source type	Battery, DC
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	51 mm
Width	103 mm
Height	54 mm
