Storage Temperature -20 to 70 C
Ambient Operating Temperature 0 to 50 C (up to 6 kHz carrier, derate above 6 kHz)
Ambient Humidity < 95% (non-condensing)
Maximum Altitude 3300 ft (1000 m) above sea level (without derating)
Input Line Voltages 120/208/240 Vac, 208/240 Vac, 400/480 Vac, 480/590 Vac
Input Voltage Tolerance +10%, -15%
Input Frequency Tolerance 48 to 62 Hz
Output Wave Form Sine Coded PWM
Output Frequency 0 - 240 Hz (consult factory for higher output frequencies)
Carrier Frequency 4 kHz to 10 kHz
Service Factor 1.00 (up to 6 kHz carrier, derate above 6 kHz)
Efficiency Up to 98%
Power Factor (displacement) 0.96 or better
Overload Current Capacity 150% for 60 seconds, 180% for 30 seconds
Speed Reference Follower 0-10 VDC, 4-20 mA
Control Voltage 15 VDC
Power Supply for Auxiliary Relays 50 mA at 12 VDC
Analog Outputs 0 - 10 VDC or 2 - 10 VDC: Proportional to frequency or load
Digital Outputs Open-collector outputs: 50 mA at 30 VDC
4.0 SCF SPECIFICATIONS
MODEL OUTPUT
NUMBER INPUT CURRENT POWER CURRENT
(NOTE 1) HP kW PHASE (AMPS) (kVA) (AMPS)
0 - 230 / 200 / 230 Vac STD THRU
SF103S 0.25 0.20 1 6.0 / 3.5 / 3.0 0.72 1.4 / 1.6 / 1.4 21 N/A
SF105S 0.5 0.37 1 9.2 / 5.3 / 4.6 1.1 2.2 / 2.5 / 2.2 28 N/A
SF110S 1 0.75 1 16.6 / 9.6 / 8.3 2.0 4.2 / 4.8 / 4.2 48 14
SF115S 1.5 1.1 1 24 / 13.9 / 12.0 2.9 6.0 / 6.9 / 6.0 73 17
NOTE 1: See Section 3.0 for model number breakdown.
NOTE 2: The first current ratings listed are for 120 Vac input, the second current ratings are for 208 Vac input,
and the third current ratings are for 240 Vac input. 120 Vac input yields three phase 230 Vac output.
NOTE 6: STD = standard unit; THRU = through-hole mount unit. Values are worst-case (not typical) for 6kHz
carrier frequency at full speed and full load.
HEAT LOSS
(WATTS)
120 / 208 / 240 Vac
FOR MOTORS INPUT (50-60 Hz)
RATED
SF100 SERIES (NOTE 2)
(NOTE 6)
5.0 SCF RATINGS
