AC Tech SCF SERIES - SCF Model Designation Code

6
SF 2 10 Y
Series:
SF = SCF Series Variable Speed AC Motor Drive
Input Voltage:
1
2
4
5
= 120/208/240 Vac (For 110 to 120 Vac and 208 to 240 Vac; 50 or 60 Hz)
= 208/240 Vac (For 208, 220, 230, and 240 Vac; 50 or 60 Hz)
= 400/480 Vac (For 380, 415, 440, 460 and 480 Vac; 50 or 60 Hz)
= 480/590 Vac (For 460, 480, 550, 575 and 600 Vac; 50 or 60 Hz)
Horsepower:
03
05
10
= ¼ Hp
= ½ Hp
= 1 Hp
15
20
30
= 1½ Hp
= 2 Hp
= 3 Hp
50
75
100
= 5 Hp
= 7.5 Hp
= 10 Hp
150
200
250
= 15 Hp
= 20 Hp
= 25 Hp
Input: Phase:
S
Y
= Single phase input only
= Single or three phase input
No character indicates three phase input only
Mounting Style:
F
F1
= Through-hole mount with special heatsink
= Through-hole mount without heatsink (customer supplies heatsink)
No character indicates panel or DIN rail mounting
Application Specific Options:
P
V
= PI (setpoint control) software
= High Frequency Output – up to 1000 Hz
3.0 SCF MODEL DESIGNATION CODE
The SCF model number gives a full description of the basic drive unit (see example below).
EXAMPLE: SF210Y (SCF Series, 208/240 Vac, 1 HP, single or three phase input)
