29 SM01P
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
12
TB-13E INPUT
FUNCTIONS
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #3 (04), INCREASE FREQ (05),
START FORWARD (06), EXTERNAL FAULT (07),
INVERSE EXT FAULT (08), AUX. STOP (09),
ACCEL/DECEL #2 (10),
NONE (01)
TB-13E OUTPUT
FUNCTIONS
RUN (11), FAULT (12), INVERSE FAULT (13),
FAULT LOCKOUT (14), AT SET SPEED (15),
ABOVE PRESET #3 (16), CURRENT LIMIT (17),
AUTO SPEED (18), REVERSE (19),
DYNAMIC BRAKING (20),
OTHER FUNCTIONS REMOTE KEYPAD (21)
14 CONTROL
TERMINAL STRIP ONLY (01)
REMOTE KEYPAD ONLY (02)
TERMINAL
STRIP ONLY
(01)
16 UNITS EDITING TENTHS OF UNITS (01), WHOLE UNITS (02)
WHOLE
UNITS (02)
17 ROTATION
FORWARD ONLY (01),
FORWARD AND REVERSE (02)
FORWARD
ONLY (01)
19 ACCELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC
20 DECELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC
21 DC BRAKE TIME 0.0 - 3600.0 SEC 0.0 SEC
22 DC BRAKE VOLTAGE 0.0 - 30.0 % 0.0 %
23 MINIMUM FREQUENCY 0.0 - MAXIMUM FREQUENCY 0.0 Hz
24 MAXIMUM FREQUENCY MINIMUM FREQUENCY - 240 Hz
SCL = 50.0 Hz
SCM = 60.0 Hz
25 CURRENT LIMIT 30 - 180 % 180 %
26 MOTOR OVERLOAD 30 - 100 % 100 %
27 BASE FREQUENCY 25.0 - 500.0 Hz
SCL = 50.0 Hz
SCM = 60.0 Hz
28 FIXED BOOST 0.0 - 30.0 % 1.0 %
29 ACCEL BOOST 0.0 - 20.0 % 0.0 %
To Next Page
