SM01P 8
5 SCL/SCM RATINGS
SCM SCL FOR INPUT OUTPUT HEAT
MODEL MODEL MOTORS
(50 - 60 Hz) (3 phase)
LOSS
1
NUMBER NUMBER
RATED
INPUT CURRENT POWER CURRENT
(WATTS)
HP kW
PHASE (AMPS) (kVA) (AMPS)
120 Vac INPUT MODELS 120 Vac 0 - 230 Vac
SM004S N / A 0.33 0.25 1 6.8 0.8 1.7 29
SM005S N / A 0.50 0.37 1 9.2 1.1 2.4 33
SM010S N / A 1 0.75 1 16.6 2.0 4.2 57
SM015S N / A 1.5 1.1 1 24 2.9 6.0 86
208 / 240 Vac INPUT MODELS 208 / 240 Vac 0 - 208 / 230 Vac
SM204S SL204S 0.33 0.25 1 3.9 / 3.4 0.8 1.9 / 1.7 23
SM205S SL205S 0.50 0.37 1 5.8 / 5.0 1.2 2.8 / 2.4 31
SM205 N / A 0.50 0.37 3 3.1 / 2.7 1.1 2.8 / 2.4 31
SM208S SL208S 0.75 0.55 1 6.9 / 6.0 1.4 3.7 / 3.2 34
SM210S SL210S 1 0.75 1 10.6 / 9.2 2.2 4.8 / 4.2 47
SM210 N / A 1 0.75 3 5.8 / 5.1 2.1 4.8 / 4.2 47
SM215S SL215S 1.5 1.1 1 13.9 / 12.0 2.9 6.9 / 6.0 68
SM215 N / A 1.5 1.1 3 8.0 / 6.9 2.9 6.9 / 6.0 68
SM220S SL220S 2 1.5 1 18.4 / 16.0 3.1 8.1 / 7.0 71
SM220 N / A 2 1.5 3 9.1 / 7.9 3.3 8.1 / 7.0 71
SM230S SL230S 3 2.2 1 24 / 21 4.1 11.0 / 9.6 108
SM230 N / A 3 2.2 3 12.4 / 10.8 4.5 11.0 / 9.6 108
SM250 N / A 5 4.0 3 19.6 / 17.1 7.1 17.5 / 15.2 173
SM275 N / A 7.5 5.5 3 28 / 25 10.3 25 / 22 286
SM2100 N / A 10 7.5 3 34 / 32 13.1 30 / 28 379
SM2150 N / A 15 11 3 54 / 48 20.0 48 / 42 476
400 / 480 Vac INPUT MODELS 400 / 480 Vac 0 - 400 / 460 Vac
SM405 N / A 0.50 0.37 3 1.6 / 1.4 1.1 1.3 / 1.1 31
SM410 N / A 1 0.75 3 3.0 / 2.5 2.1 2.5 / 2.1 47
SM415 N / A 1.5 1.1 3 4.3 / 3.6 3.0 3.6 / 3.0 58
SM420 N / A 2 1.5 3 4.8 / 4.0 3.3 4.1 / 3.4 63
SM430 N / A 3 2.2 3 6.4 / 5.4 4.5 5.8 / 4.8 92
SM450 N / A 5 4.0 3 10.6 / 8.8 7.1 9.4 / 7.8 155
SM475 N / A 7.5 5.5 3 14.2 / 12.4 10.3 12.6 / 11.0 254
SM4100 N / A 10 7.5 3 18.1 / 15.8 13.1 16.1 / 14.0 310
SM4150 N / A 15 11 3 27 / 24 20.0 24 / 21 390
1
Values shown for 6kHz carrier frequency at full speed and full load.
