Accu-Chek Compact Plus Owner's Booklet

47
Preparing the Lancing Device for Fingertip Testing
WARNING
Useanewlancetforeachngersticktoavoidinfection.
1. Make sure the black cap is on
the lancing device. Do not use
the AST cap to perform a
ngertip test.
2. Twist the cap to set the depth.
The depth indicator shows the
current depth selection.
The higher the number, the
deeper the penetration. If you
have soft skin, we suggest
starting at a depth of 2. If your
skin is calloused or thick, try a
higher setting.
man_07699336001_01_EN.indb 47 28.09.2015 13:26:25

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
