Initial steps before testing
2
 Insert a new test strip drum in the meter as illustrated (the words
“Accu-Chek Compact” must be nearest the display window).
 Close the drum compartment cover and push it shut. There will be
an audible CLICK.
The meter turns on and rotates the test strip drum until the first test
strip is in the correct position. At the same time the meter reads the bar
code that provides it with information on the specific characteristics of
the test strips. After that, the meter turns off.
man_06919570001_01_EnCan.indd 27 18.01.2013 18:38:03

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
