Accu-Chek Guide User Manual

113
Technical Information
10
Product Limitations
See the literature packaged with the test strips and control solutions for the latest information on product
specifications and limitations.
Specifications
Blood volume
Sample type
Measuring time
Measuring range
Test strip storage conditions
System operating conditions
Refer to the test strip package insert.
Meter storage conditions Temperature: ‑13–158°F
Memory capacity 720blood glucose results and 32control results with time
and date
Automatic o 90seconds
Power supply Two3‑volt lithium batteries (coin cell type CR2032)
Display LCD
Dimensions 80 × 47 × 20 mm (LWH)
Weight Approx. 40g (with batteries)
Construction Hand‑held
Protection class III
Meter type The Accu‑Chek Guide meter is suitable for continuous
operation.
Control solution storage conditions Refer to the control solution package insert.
Interfaces
USB: micro‑B connector; Bluetooth Low Energy;
Continua Certified
®
to a Continua Certified manager.
Radio frequency connectivity Bluetooth low energy technology operating in the frequency
band of 2402 MHz to 2480 MHz with a maximum
transmitted power of 0 dBm (1 mW).
Chapter 10: Technical Information
54988_08100918001_EN.indb 113 9/30/16 5:04 PM

Accu-Chek Guide Specifications

General

Measurement Range	10 to 600 mg/dL
Test Time	Less than 4 seconds
Battery Life	Approximately 1000 tests
Connectivity	Bluetooth
Sample Size	0.6 μL
Weight	Approx. 40 g (1.4 oz) with battery
Battery Type	2 x CR2032 lithium coin cells
Display	LCD
Operating Conditions	10-40°C (50-104°F), 10-90% relative humidity
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
