Accu-Chek Guide User Manual

26
Blood Glucose Tests
3
Wash your hands with warm
soapy water and dry thoroughly.
Dirty or wet hands could affect
test results.
1
Adjust the comfort dial. Check the Use By date on the
test strip container.
Do not use test strips past the
Use By date.
Remove a test strip from the
test strip container. Close the
cap tightly.
2 3
4
Insert the metallic end of the
test strip into the meter.
The meter turns on. Preparing
to test appears.
5
54988_08100918001_EN.indb 26 9/30/16 5:04 PM

Accu-Chek Guide Specifications

General

Measurement Range	10 to 600 mg/dL
Test Time	Less than 4 seconds
Battery Life	Approximately 1000 tests
Connectivity	Bluetooth
Sample Size	0.6 μL
Weight	Approx. 40 g (1.4 oz) with battery
Battery Type	2 x CR2032 lithium coin cells
Display	LCD
Operating Conditions	10-40°C (50-104°F), 10-90% relative humidity
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
