Accu-Chek Performa Nano User Manual

6. Squeeze the bottle until a tiny drop
forms at the tip. Touch the drop to the
front edge of the yellow window of the
test strip. When you see
flash, you
have enough control solution in the test
strip. Wipe the tip of the bottle with a
tissue then cap the bottle tightly.
7. The result appears on the display, along
with the control bottle symbol and
flashing “L.” Do not remove the test
strip yet. Press
once to mark the
result as a Level 1. If you tested the
Level 2 control, press
a second
time.
OR
55
43149_NanoPerf_24MSTR_Ins.indd 5543149_NanoPerf_24MSTR_Ins.indd 55 11/25/08 2:49:07 PM11/25/08 2:49:07 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
