SwitchSpeed™ Controller Manual V1.3 © 2009 AccuAir Control Systems, L.L.C.
- Page 9 -
Setup Programming:
Choosing Which Speed To Adjust
Select which speed you wish to
modify. The selected speed will
ash to display the rate that the
valves will be pulsed at.
(Description on Pg. 10)
150 200175
ALL-DOWN MODE TYPE.
(Description on Pg. 11)
Tank Pressure Mode: (Optional)
150 psi = White only
175 psi = White & Red alternating
200 psi = Red only
(Description on Pg. 12)
Adjusting Speeds:
(Description on Pg. 10)
DECREASE:
DECREASE:
TIMER:
INCREASE:
Valve
ON-Time
INCREASE:
Valve
OFF-Time
MOMENTARY:
To check or change any of the programmed settings during operation, press the
Program “ ” Button momentarily to initiate Programming Mode:
NOTE: Program Mode will exit after 5 seconds or can be exited by pressing
the Program Button again and your changes will be saved.
Adusting Valve Speed:
To Next Page
