Accuphase DP-77 Service Information

Caution for AC line Voltage Selection
注意 ： 電源電圧の変更
The unit can be used with differnt voltage of 100V,120V,230V.
(Use the Japanese domestic model at 100V only, and never change the voltage in Japan.)
Refer the photo and illustration for the wiring on the junction terminal as shown below,
andhavetoselectthecorrectfuseandpowersupplycord.
電源電圧は 、 100V､120V､230V に対応でき ますが以下はその方法を示し ます 。
（ 日本国内は100V仕様ですので 、 この電圧以外の変更は出来ません ）
電源電圧の変更をする場合は 、 フ ュ ーズ 、 電源 コ ー ド は以下の指定された コー ド を使用 し ます 。
CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE REPLACEMENT ONLY WITH
SAME TYPE FUSE. (See above table)
100V WHT,BLUBLK
BLK
BRN
1
FUSE/ﾌｭｰｽﾞ
T1.25A L AC250V
(310-1104-00)
T630mA L AC250V
(310-1061-00)
AC Cord /電源ｺｰﾄﾞ
J type : 680-1404-00
U type : 680-2401-00
E type : 680-3402-00
－１２－
Photo is shown
Japanese model
wiring.
写真は日本国内
ﾓﾃﾞﾙの配線を示す
120V
230V
2(～)3
4(～)
WHT,BLU
WHT,BLU
BRN,ORG
YEL,ORG
BLK,ORG
YEL
BRN
YEL
100V WHTBLK
BLK
BRN
1
120V
230V
234
WHT
WHT
BRN
YEL
BLK
YEL
BRN
YEL
For 510-4032-00For 510-4031-00
100V
120V
230V
510-4032-00
１
２
３
４
510-4031-00
N
(W)
301-3306-00
T630mA L 250V at 220-240V
T1.25A L 250V at 100-120
V
FUSE: :
100V
120V
230V
BLK
BLK
BRN
12(~)34(~)
VOLTAGE SELECTION TABLE
WHT-BLU YEL
BRN
YEL
BRN-ORG
YEL-ORG
BLK-ORG
1
K1
POWER SWITCH Ass'y
726-0143-00
K1
2
3
4
POWER TRANSFORMER
510-4031-00
WHT
BRN
YEL
BLK
WHT-BLU
WHT-BLU
POWER TRANSFORMER
510-4032-00
WHT
BRN
YEL
BLK
RED.GRY.RED
BLU.WHI.BLU
YEL. BLK. YEL
(RED.GRN.ORG.YEL.BLU)
*
ORG
BLU
BLU
C001
103/2E
AC 100/120/230V
50/60Hz
電源ﾄﾗﾝｽ
電源ﾄﾗﾝｽ

Accuphase DP-77 Specifications

Optical Specifications

SACD wavelength	650 nm
CD wavelength	780 nm
Optical output wavelength	660 nm

Digital Processor Specifications

Sampling frequencies	32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
High sampling frequencies	176.4kHz, 192kHz
Dynamic range	114 dB

Power

AC voltage	120V/230V 50/60Hz
Power consumption	24 W
Net weight	17.7 kg

Weight and Dimensions

Width	475 mm
Height	151 mm
Depth	397 mm
