Accuphase DP-77 Service Information

1 2
IC201A
TC74VH C U 04F
3V
GND
VCC
C201
103
3 4
IC201B
TC74VH C U 04F
5 6
IC201C
TC74VH C U 04F
9 8
IC201D
TC74VH C U 04F
11 10
IC201E
TC74VH C U 04F
13 12
IC201F
TC74VH C U 04F
I1
I2
I3
I4
I5
I6
O1
O2
O3
O4
O5
O6
R106
103
C105
680
C106
4R7
XTAL101
527-0038-00
22.5792MHz
R104105
D101
HVM17
VCC
Q101
2SC982TM _
R101
102
C102
2R2
/1H
R102
393
R103
102
C103
224
VCX44E
PD
5V-OSC
5V-FIL
C101
103
GND
1
2
3
IC101A
TC74HC 00A F
R105
471
R109
103
C107
680
C108
4R7
XTAL102
527-0039-00
24.576MHz
R107105
D102
HVM17
12
13
11
IC101D
TC74HC 00A F
R108
471
9
10
8
IC101C
TC74HC 00A F
4
5
6
IC101B
TC74HC 00A F
VCX512F S
C104
471
/0J
VCX48E
VCC
C111
104
C109
471
/0J
C110
471
/0J
-17-
D P - 7 7  D S P  A S S ' Y ( 7 2 4 - 0 0 4 1 - 0 0 - 1 )
DSPASS'Y(724-0041-00-2)

Accuphase DP-77 Specifications

Optical Specifications

SACD wavelength	650 nm
CD wavelength	780 nm
Optical output wavelength	660 nm

Digital Processor Specifications

Sampling frequencies	32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
High sampling frequencies	176.4kHz, 192kHz
Dynamic range	114 dB

Power

AC voltage	120V/230V 50/60Hz
Power consumption	24 W
Net weight	17.7 kg

Weight and Dimensions

Width	475 mm
Height	151 mm
Depth	397 mm
