Accuphase DP-77 Service Information

FRONT VIEW
(
前面
)
REAR VIEW
(
面後
)
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /2pcs.
(302-0116-00)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ/4pcs.
(254-2015-04)
Foot
脚
(238-0023-00)
Square Plate
ｽﾛｯﾄﾊﾟﾈﾙ
(159-0069-14)
XLR (Cannon) Plug Receptacle
ｵｰﾃﾞｨｵｺﾈｸﾀﾌﾟﾗｸﾞ /2pcs.
(301-8005-00)
Connector Cover /Male
ｺﾈｸﾀｶﾊﾞ /2pcs.
(254-2011-00)
AC Inlet
AC ｺﾈｸﾀﾌﾟﾗｸﾞ
(301-3306-00)
＊Power Supply Cord
電源ｺｰﾄﾞ
J type:680-1404-00
U,T type:680-2401-00
E type:680-3402-00
Rear Panel
ﾊﾞｯｸﾊﾟﾈﾙ
(135-0158-02)
Front Panel Assebly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0169-01)
1 Front Panel=131-0169-01
ﾌﾛﾝﾄﾊﾟﾈﾙ
2 Sub-panel =134-0138-03
ｻﾌﾞﾊﾟﾈﾙ
3 Tray Sub-panel=134-0130-04
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙ
4 Push-button/5-gang=388-5059-13
ﾌﾟｯｼｭﾎﾞﾀﾝ /5連
5 Decoration Screw=630-0304-14
飾りﾈｼﾞ
5-1 Washer=637-9045-04
ﾜｯｼｬ
5-2 Nut=633-2032-02
六角ﾅｯﾄ
6 Front Glass=172-0116-03
ﾌﾛﾝﾄｶﾞﾗｽ
1pce.
1pce.
1pce.
1pce.
2pcs.
2pcs.
2pcs.
1pce.
6 Display Assembly=723-0081-00
ﾃﾞｨｽﾌﾟﾚｨAss'y
6-1 Fixed Bracket=159-0097-03
化粧板
6-2 Rubber Cussion=250-2140-04
ｺﾞﾑｸｯｼｮﾝ
6-3 Filter=179-0029-04
ﾌｨﾙﾀｰ
7 Push-button=388-5044-03
ﾌﾟｯｼｭﾎﾞﾀﾝ/POWER
7-1 Push-button Frame=113-0100-14
ﾌﾟｯｼｭﾎﾞﾀﾝﾌﾚｰﾑ
7-2 Coil Spring=285-1016-04
ｺｲﾙｽﾌﾟﾘﾝｸﾞ
7-3 E-ring=647-1054-00
Eﾘﾝｸﾞ
8 Panel End-cap=132-0098-04
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
2pcs
.
1
2
6
5
4
37
－
2
－
Decoration Screw
飾りﾈｼﾞ/4pcs.
(630-0302-04)
Washer
ﾜｯｼｬ
(637-9045-04)
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /2pcs.
(302-0116-00)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ/4pcs.
(254-2015-04)
Optical Rceiver
ｵﾌﾟﾄﾚｼｰﾊﾞ /IC4
(GP1FA513RZ)
Knob
ﾂﾏﾐ
(383-1201-03)
Binding Serew /脚用
ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄ /4×14
(611-0414-02)
Optical Rceiver
ｵﾌﾟﾄﾚｼｰﾊﾞ /IC2
(GP1FA513TZ)
8 8

Accuphase DP-77 Specifications

Optical Specifications

SACD wavelength	650 nm
CD wavelength	780 nm
Optical output wavelength	660 nm

Digital Processor Specifications

Sampling frequencies	32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
High sampling frequencies	176.4kHz, 192kHz
Dynamic range	114 dB

Power

AC voltage	120V/230V 50/60Hz
Power consumption	24 W
Net weight	17.7 kg

Weight and Dimensions

Width	475 mm
Height	151 mm
Depth	397 mm
