MISCELLANEOUS
(本体その他使用部品)
No.
C001
Packing
Material
梱包材
Description
PC Board for
DSP Ass'y
DAC Ass'y
IO Ass'y
Mother Board Ass'y
SACD Kit / ｷｯﾄ
RF Board /RF ﾎﾞｰﾄﾞ
Main Board /ﾒｲﾝﾎﾞｰﾄﾞAss'y
Optical Pick-up /光ﾋﾟｯｸｱｯﾌﾟ
Switch Assembly /ｽｲｯﾁAss'y
Loading Motor /ﾛｰﾃﾞｨﾝｸﾞﾓｰﾀｰ
Belt / ﾍﾞﾙﾄ
Fuse T1.25A L 250V
ﾌｭｰｽﾞ T630mA L 250V
Metalized Polyester
Capacitor
ﾒﾀﾗｲｽﾞﾄﾞﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
Outer Carton Box
ﾀﾞﾝﾎﾞｰﾙ箱
Top Pad (F)
ﾄｯﾌﾟﾊﾟｯﾄﾞF
Top Pad(R)
ﾄｯﾌﾟﾊﾟｯﾄﾞR
Bottom Pad(F)
ﾎﾞﾄﾑﾊﾟｯﾄﾞF
Bottom Pad(R)
ﾎﾞﾄﾑﾊﾟｯﾄﾞR
Top Board /天地当板
Cover /保護ｶﾊﾞ
Accessories Case /付属品ｹｰｽ
Wrapping Sheet /ｼｰﾄ
Bag for AC Cord,Remote,
Audio Cord
Poly Bag /ﾋﾞﾆｰﾙ袋 for Manual
Cover /保護ｶﾊﾞ for Remoote
Part No.
115-1436-00
115-1438-10
115-1439-10
115-1441-10
731-0007-00
1-679-092-11
1-679-080-12
8-820-132-03
1-641-764-11
1-641-765-11
4-927-649-01
310-1104-00
310-1061-00
CF99MF2E103M
801-0243-14
803-0324-00
803-0325-00
803-0326-00
803-0327-00
803-0033-14
810-4843-04
801-0251-10
810-4545-04
810-2030-04
810-2030-04
812-2435-04
810-1030-00
Remarks
not supplied
KHM-230AAA/J1RP
for 100-120V
for 220-240V
0.01uF/250V
(前)
(後)
(前)
(後)
(本体)
ACｺｰﾄﾞ,ﾘﾓｺﾝ
ｵｰﾃﾞｨｵｺｰﾄﾞ
取説用
ﾘﾓｺﾝInner用
No.
Screws
for
ﾈｼﾞ類
Accessories
付属品
Description(部品名)
Front Panel /ﾌﾛﾝﾄﾊﾟﾈﾙ用ﾈｼﾞ
Binding Screw /ﾊﾞｲﾝﾄﾞﾂﾒﾂｷ
Top Plate Ass'y /ﾄｯﾌﾟﾌﾟﾚｰﾄ
Round Head Screw /ﾌﾞﾚｻﾞｰﾂﾒﾂｷ
Binding Screw /ﾊﾞｲﾝﾄﾞﾞﾂﾒﾂｷﾈｼﾞ
Side Panel /ｻｲﾄﾞﾊﾟﾈﾙ
Oval Head Screw /丸ｻﾗﾈｼﾞ
Binding Screw /ﾊﾞｲﾝﾄﾞﾈｼﾞ
Washer /ﾜｯｼｬ
Bottom Plate /ﾎﾞﾄﾑﾌﾟﾚｰﾄ
Binding Screw /ﾊﾞｲﾝﾄﾞﾂﾒﾂｷﾈｼﾞ
Foot / 脚用
Binding Screw /ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄﾈｼﾞ
Option Slot Panel/ ｵﾌﾟｼｮﾝｽﾛｯﾄﾊﾟﾈﾙ
Decoration Screw /飾りﾈｼﾞ
Washer /ﾜｯｼｬ
Power Transforer/ﾊﾟﾜｰﾄﾗﾝｽ用
Binding Screw /ﾊﾞｲﾝﾄﾞﾈｼﾞ
Spring Washer /ｽﾌﾟﾘﾝｸﾞﾜｯｼｬ
Owner's Manual
取扱説明書
Notes
注意書
Power Supply Cord (J type)
電源ｺｰﾄﾞ (U,T type)
(E type)
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞｰ
Battery / 電池
Audio Cord (L)/ ｵｰﾃﾞｨｵｺｰﾄﾞ
Audio Cord (R)/ ｵｰﾃﾞｨｵｺｰﾄﾞ
Pin Jack Cover / ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
Connector Cover for male
ｺﾈｸﾀｶﾊﾞ
Part No.
631-0047-00
616-0306-02
631-0054-00
612-0308-00
604-0408-00
637-0042-07
631-0054-00
611-0414-02
630-0302-04
637-9045-04
604-0408-02
638-0041-02
820-2213-00
820-0213-00
821-0011-00
821-0010-00
680-1404-00
680-2401-00
680-3402-00
729-0028-00
569-0006-00
685-0416-10
685-0417-10
254-2015-04
254-2011-00
Remarks
3×8mm 6pcs.
3×6mm 6pcs.
3×10mm 2pcs.
3×8mm 4pcs.
4×8mm 4pcs.
4mm dia. 4pcs.
3×10mm 9pcs.
4×14mm 4pcs.
4pcs.
4pcs.
4×8mm 8pcs.
8pcs.
English
Japanese
English
Japanese
2-conductor
2-conductor
3-conductor
RC-28
R03 /UM-4/単4
White /1m
Red /1m
4pcs.
2pcs./出力用
－５－
SACD
Laserdiodens specifikationer Laserdiodespecifikationer Laserdiode-spesifikasjoner Laserdiodin ominaisuudet
*Materi al: GaAlAs *Material e: GaAlAs *Materiale : GaAlAs *Materiaal i: GaAlAs
*Våglängd: 780nm *Bølgelængde: 780nm *Bølgelengde: 780nm *Aallonpituus: 780nm
*Laseruteffekt: 28.5uW *Laserudgangseffekt:28.5uW *Laserutgangseffekt: 28.5uW *Laserin teho: 28.5uW
Laserdiodens specifikationer Laserdiodesp ecifikation er Laserdiode-spesifikasjoner Laserdiodi n ominaisuudet
*Material: AlGalnP *Materiale: AlGalnP *Materiale: AIGalnP *Materiaali: AIGalnP
*Våglängd: 650nm *Bølgelæn gde: 650nm *Bølgelengde: 650nm *Aallonpituus: 650nm
*Laseruteffekt: 73.7uW *Laserudgangseffekt:73.7uW *Laserutgan gseffekt:73.7uW *Laserin teho: 73.7uW
CD
CAUTION-INVI SIB LE LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO BEAM
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
VARNING-LASERSTRÅLNING NÄR DENNA DEL AR ÖPPNAD
STRÅLEN ÄR FARLIG
VARO!-AVATTAESSA OLET ALTTIINA LASERSÄTEILYLLE
ÄLÄ KATSO'SÄTEESEN BETRAKTA EJ STRÅLEN
ADVARSEL-LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÅLING
ADVARSEL-LASERSTRÅLING NÅR DEKSEL ÅPNES
UNNGÅ EKSPONERING FOR STRÅLEN
Please perform lens cleaning of an optical pickup by air blow
.
The cleaning in a swab etc. causes failure.
光ﾋﾟｯｸｱｯﾌﾟのﾚﾝｽﾞｸﾘｰﾆﾝｸﾞはｴｱｰﾌﾞﾛｱｰで行って下さい。
綿棒などでのｸﾘｰﾆﾝｸﾞは故障の原因となります。
