2-14-10 SHIN-ISHIKAWA, AOBA-KU, YOKOHAMA, JAPAN
2003-12 861-3135-00
Printed in Japan
SPECIFICATIONS
[Guaranteed specifications measured according to EIAJ standard CP-2402]
2-channel Super Audio CD, CD
Non-contact optical pickup
SACD :650 nm
CD :780 nm
HS-Link Connector type :RJ-45
Suitable cable :Dedicated HS-Link cable
Format :EIAJ CP-1201 compliant
COAXIAL :0.5Vp-p,75ohms
OPTICAL :-21to-15dBm,wavelength660nm
2
チャンネル
Super Audio CD
CD
非接触光学式
SACD
:650nm
CD
:780nm
HS-Link
コネクタ
:RJ-45
合ケーブル
:HS-Link
用ケーブル
フォーマット
:EIAJ CP-1201
準拠
COAXIAL :0.5Vp-p 75
Ω
OPTICAL : -21~-15dBm
660nm
[Measurement disc :PHILIPS 3122-783-00632]
[Transport Section]
COAXIAL Format : EIAJ CP-1201/AES-3 compliant
OPTICAL Format : EIAJ CP-1201 compliant
Sampling frequencies
32kHz,44.1kHz,48kHz,88.2kHz,96kHz
(16 to 24bits,2-channel PCM)
Implemented by option board
176.4kHz,192kHz(24bit,2-channel PCM)
2.8224MHz (1 bit, 2-channel DSD)
24-bit MDS Plus converter
0.5
50,000Hz +0,-3dB
0.0008% (20 to 20,000Hz)
114dB
110dB (24-bit input, low-pass filter off)
108dB (20 to 20,000Hz)
BALANCED :2.5V at 50 ohms,balanced XLR type
UNBALANCED :2.5V at 50 ohms,RCA phono jack
0 to -60dB,HV 1-dB steps (digital)
[Digital Processor Section]
AC 120V/230V 50/60Hz (Voltage as indicated on rear panel)
24W
Width 475 mm (18-7/10")
Height 151mm (5-15/16")
Depth 397mm (15-5/8")
17.7 kg (39.0lbs) net
23.0 kg (51.0lbs) in shipping carton
Remote control principle :Infrared pulse
Power supply :Two IEC R03 (size AAA) batteries
Dimensions : 66x175x20mm
Weight : 220g(including batteries)
[General]
COAXIAL
フォーマット
:EIAJ CP-1201 /AES 3
準拠
OPTICAL
フォーマット
:EIAJ CP-1201
準拠
サンプリング周波数
32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
(
16
24 bit 2ch. PCM)
オプションボードに
176.4kHz, 192kHz (
24bit 2ch PCM)
2.8224MHz (1bit 2ch. DSD)
24
ビット
MDS plus
方式
0.5
50,000Hz +0
-3dB
0.0008% (20~20,000Hz間)
114dB
110dB (24bit
入力、
LPF :OFF)
入力端子 定格出力時
EIA(1W
出力
)
力インピーダンス
108dB (20
20,000Hz)
BALANCED :2.5V 50
Ω平
XLR
タイプ
UNBALANCED :2.5V 50
Ω
RCA
フォノジャック
0
-60dB
1dB
ステップ
(
ディジタル
)
AC100V 50 /60Hz
24W
475mm
×高さ
151mm
×奥行
397mm
17.7kg
リモコン
:
線パルス
電源
:
4
型電池
2
個使用
最大外形寸法
:66
㎜x
175
㎜x
20
質量
: 220g(
電池含む
)
