SP8026-1909
EVOLUTION ELECTRIC STEAMER
12
Component Part # Purpose
Temperature
(RTD)
Sensor
AT0E-3626-1
• Provides temperature input to Control/Keypad Board, which dis-
plays the temperature in the steam chamber based on resistance
changes from the Temperature (RTD) Sensor.
• Used to maintain the preset HOLD mode temperature.
Door Assembly AT1A-3600-1
• Keeps the steam trapped inside the steam chamber to allow
pressure to build and cycle the Chamber Pressure Switch.
Drain Valve AT1P-2239-1
• Manually Open/Close valve used to drain water from the
steam chamber.
ADDITIONAL COMPONENT PART NUMBERS
Component Part # Component Part #
Pilot Lamp, 24V Red AT0E-1800-2 Inner Door Assembly AT1A-3647-1
Fuse, Slo-Blo 1.25A AT0E-2731-1 Door Hinge (Pair) AT1H-2058-3
Door Latch Assy, Ceramic
Magnet
AT1H-3609-1 Door Latch Mounting Plate AT1M-3046-1
Gasket, Door AT1G-2633-1
2.0 Main Component Information
Cast Heater
Replacement Kit
6 KW:
AT1A-3530-1
8 KW:
AT1A-3530-2
10 KW:
AT1A-3530-3
12 KW:
AT1A-3530-4
14 KW:
AT1A-3530-6
17 KW:
AT1A-3530-7
• Transfers the heat, generated from the internal elements; to boil
the water to create steam.
• Cast Heater can be wired to single or 3 phase; and have a parallel,
delta, or wye configuration.
• Cast Heater must be replaced with the same wattage heater as
specified in the model number.
