SP8026-1909
EVOLUTION ELECTRIC STEAMER
3
TABLE OF CONTENTS
Warnings and Cautions
1.0 Sequence of Operation
1.1 Water Level System
1.2 Heat Generation
1.3 Temperature Sensor and Control
board
2.0 Main Component Information
3.0 Troubleshooting Flowchart
3.1 Troubleshooting Table
3.2 Troubleshooting Notes
3.3 Modifying Control Settings
3.4 Location of Electrical Components
3.6 Recommended Tools
4.0 Removal and Replacement of
Components
4.1 R&R of Supply Power Components
4.2 R&R of Water Level Control
Components
4.3 R&R of Heat Control Components
4.4 R&R of Cast Heater
4.5 R&R of Door Assembly
4.6 R&R of Temperature Sensors
4.7 Steam Vent Components
5.0 Wiring Schematics
5.1 Wiring Schematic for SN 36980
and Below
5.2 Wiring Schematic for SN 36981
and Above
4
7
7
8
9
10
13
14
25
26
28
29
30
32
36
38
43
47
48
50
51
