b. The unit should not be located near any heat source.
c. The unit shall be located on a solid level foundation at normal countertop height.
d. There must be at least 2 inches of clearance at the rear and 10 inches at the front to allow
for door opening and good airflow.
e. Do not place anything on top of the ice machine.
To ensure proper ventilation of the ice machine, the front of the unit must be completely
unobstructed (at least 8 inches of free space). Leave at least 2 inches of clearance at the back and
at least 2 inches at the top and sides for air circulation. If necessary, the installation should allow
the ice machine to be pulled forward for servicing.
When installing the ice machine under the counter, follow the recommended spacing dimensions
shown above. Place power, water, and drain fittings in the recommended locations as shown.
Choose a well-ventilated area with temperatures above 50 degrees Fahrenheit and below 90
degrees Fahrenheit. The unit must be installed where it is not affected by elements such as wind,
rain, water spray or dripping water. The ice machine requires a continuous water supply at a
pressure of 6-87 psi, as required by the spec sheet above. The temperature of the water entering
the ice machine should be between 41 and 77 degrees Fahrenheit to function properly.
Electrical Requirements and Connections
WARNING: This unit must be grounded.
Electric Shock Hazard
Insert the plug into a grounded wall outlet.
Never remove the ground pin.
Use a separate power source or outlet. Never use an adapter.
Never use extension cords.
Failure to follow these instructions could result in death, fire or electric shock.
