Specification
Model HZB-65
Supply voltage 1 PH, 110-120V/60Hz
Ice making rated current 2.7A/3.0A
Size/inches 17.6 x 15.7 x 31.4
Net weight 62 lbs
Ice making capacity 150 lbs/24 hours
Refrigerant capacity R290, 3.17 Oz/90g
Foaming agent C5H10
Maximum ice storage 33 lbs
Working conditions Room temperature 50-90 degrees Fahrenheit
Water temperature 41-77 degrees Fahrenheit
Water pressure 6-87 psi
Note: Tested at 70°F room temperature and 50°F water temperature.
Figure 1
