Acer Aspire 5333 - LVDS Cable Installation

Machine Maintenance Procedures 3-45
LVDS Cable Installation 0
1. Connect LVDS cable (C) to panel connector (D) (Figure 3-46).
2. Secure connector with adhesive (B) (Figure 3-46).
3. Install and secure LVDS cable (D) to LCD panel (Figure 3-45).
4. Install LCD Panel.
