Acer Power F1 Rear Panel
Label Description
1 Power Code Socket
2 Voltage Selector Switch
3 Fan Aperture
4 PS/2 Keyboard Port
5 PS/2 Mouse Connector
6 Serial Connector
7 Printer Connector
8 Monitor Connector
9 USB Connector
10 RJ-45 Ethernet Connector
11 Microphone Jack
12 Line-Out Jack
13 Line-In Jack
14 Extension Card Slots
No. Description No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
