22 Chapter 2
IDE Channel 0/1 Master/Slave Setup
The following screen appears if you select any of the IDE drive parameters:
The following table describes the parameters found in this menu. Settings in boldface are the default and
suggested settings.
Parameter Description Options
IDE HDD Auto-
Detection
Auto-detects your hard disk drive Press [Enter]
IDE Channel 0 Master
IDE Channel 0 slave
IDE Channel 1 Master
IDE Channel 1 Slave
Display the type of device installed. Auto
None
Manual
Access Mode Selects the HDD access mode Auto
Large
LBA
CHS
Capacity Shows the size of your HDD in MB xxxxx MB
Cylinder Shows your hard disk’s numberof cylinders 0 to 65535
Head Shows your hard disk’s number of heads 0 to 255
Precomp Selects the precomp number for old HDD parking 0 to 65535
Landing Zone Selects the Land Zone number for old HDD parking 0 to 65535
Sector Shows your hard disk’s number of sectors 0 to 255
