1-38 Hardware Specifications and Configurations
Capactive Touch Module (for Touchscreens)
LCD Inverter (not available with this model)
Display Supported Resolution (LCD Supported Resolution)
Item Specification
Vendor & Model name TPK TOM15G41
OGS Corning IOX
Laminating Material OCA
Connector FPC
Connecting Accessory
material
ACF
Display LCD
Total Thickness 6.61MAX
Active Area (mm) 344.2 x 193.5
Transmittance TBD
Haze TBD
Item Specification
Vendor & Model name
Brightness conditions
Input voltage (v)
Input current (mA)
Output voltage (V, RMS)
Output current (mA, RMS)
Output voltage frequency
(KHz)
Resolution 32 bits Intel Nvidia
1024 X 768p / 60Hz 16:9 Yes Yes Yes
1280 X 768p / 60Hz 16:9 Yes Yes Yes
1360 X 768p / 60Hz 16:9 Yes Yes Yes
1366 X 768p / 60Hz 16:9 Yes Yes Yes
1920 X 1080 / 60Hz 16:9
(FHD panel only)
Yes Yes Yes
