Rear / Bottom panel view
1/16 SCART 2 COMPONENT
3 AUDIO L/R 4/15 AUDIO L/R
5/13 CVBS 6/14 S-VIDEO
7
EARPHONE 8 POWER SOCKET
9 VGA-IN 10 AUDIO-IN
11 HDMI * 12 ANALOG ANTENNA
SCART
AV-S
AV
AV Audio
Audio
Y
Pb
Pr
CO M PO N EN T
AT2011 AT2010
8
9
10
11
12
13
14
15
16
7
6
5
4
3
2
1
* HDMI only for AT2011.
