Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-3
Product Overview 1-8
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover Module 2-2
Disassemble Lamp Module 2-3
Disassemble Top Cover Module 2-4
Disassemble Key Pad Board Module 2-5
Disassemble Focus Ring 2-6
Disassemble Top Shielding 2-7
Disassemble Front Cover Module and IR Sensor Board 2-8
Disassemble Main Board 2-9
Disassemble Engine Module 2-10
Disassemble Clor Wheel Module 2-11
Disassemble DMD Board and DMD Chip 2-12
Disassemble Speaker Module 2-13
Disassemble System Fan Module 2-14
Disassemble Blower 2-15
Disassemble Front Cover 2-16
Disassemble Lamp Driver 2-16
Disassemble LVPS 2-17
Disassemble Bottom cover 2-18
Rod Adjustment 2-20
