No Item Description
15 Input signal spec
- Hsync Frequency 31.5 k ~ 100 kHz
- Vsync Frequency 50 ~ 85 Hz
- Video Signal RGB (PC)
● Analog RGB 0.7Vp-p, 75 ohm, Separate TTL H,V Sync
● Analog RGB 1Vp-p, 75 ohm, Sync. On Green signal
● Analog RGB 0.7Vp-p, 75 ohm, Composite TTL Sync- Video
● Composite video 1Vp-p,75 ohm
● S-video Luminance 0.714Vp-p, 75 ohm
● Chrominance 0.286Vp-p, 75 ohm
● Component Video 1Vp-p, 75 ohm
16 Video Compatibility
- Standards :
● NTSC (3.58/4.43)
● PAL (B/D/G/H/I/M/N)
● SECAM (B/D/G/K/K1/L)
● HDTV - 480p, 576p, 720p, 1080P
17 Brightness
Engineering spec:
- 2250 ANSI Lumens (Typical; Full power mode)
- 2000 ANSI Lumens (Minimum; Full power mode)
Marketing spec:
-2500 Lumens
18 Contrast
Engineering spec:
- 1300 : 1 Full White and Black (Minimum; Full power mode)
- 1700 : 1 Full White and Black (Typical; Full power mode)
Marketing spec:
-1900:1 Full White and Black
19 Uniformity
Engineering spec:
- 65% Japan standard (Minimum; Full power mode)
- 80% Japan standard (Typical; Full power mode)
Marketing spec:
-85%
20 Color Wheel
- 6 segments
- 7200 rpm(2X)
- 9000 rpm@3X PAL 50Hz
- 10800 rpm@3X NTSC 60Hz
Segment Angle: R85Y37G90C28W42B78
21 Temperature
- Operating: 5°C -- 35°C
- Storage: -20°C -- 60°C
22 Maximum Humidity
- Operating: 5°C -- 35°C, 80%RH (Max.), non-condensing
- Storage: -20°C -- 60°C, 80%RH (Max.), non-condensing
23 System controller - TI DDP2230
24 Number of active dots
- Number of active dots : 1024(H) x 768(V)
