ACME DVS-5000 - Home Position Adjustment

DVS-2500/5000/5000II
25B
select Yes (the fixture will reset to factory settings) or No, and press ENTER button to
store. Press MENU button to exit.
6.3. Home Position Adjustment
Press MENU button into menu mode, then hold ENTER button for about 3 seconds into
offset mode to adjust the home position. Select the function by ENTER button. Use
UP/DOWN button to choose the submenu, press the ENTER button to store and
automatically return to the last menu. Press MENU button to exit.
-128~127Pan
Tilt -128~127
Shutter
0~255
Offset Menu
Focus
0~255
Pan—pan home position adjust
Enter offset mode, Select Pan, press ENTER button to confirm, the present position will
blink on the display, use UP/DOWN button to offset the value from -128 to 127, press
ENTER button to store. Press MENU button to exit.
Tilt—Tilt home position adjust
Enter offset mode, Select Tilt, press ENTER button to confirm, the present position will
blink on the display, use UP/DOWN button to offset the value from -128 to 127, press
ENTER button to store. Press MENU button to exit.
Shutter—Shutter home position adjust
Enter offset mode, Select Shutter, press ENTER button to confirm, the present position will
blink on the display, use UP/DOWN button to offset the value from 0 to 255, press ENTER
button to store. Press MENU button to exit.
Focus—Focus home position adjust
Enter offset mode, Select Focus, press ENTER button to confirm, the present position will
blink on the display, use UP/DOWN button to offset the value from 0 to 255, press ENTER
button to store. Press MENU button to exit.
